TrueShield 100
16" Nail-Strip Standing Seam · 1" Rib
TrueShield 100 gives you clean, screw-free roof lines at a lower installed cost. Each panel has a built-in fastening flange along one edge. The installer screws through that flange into the deck, and the next panel laps over it and hides the screws completely. No clips to buy or place.
$290 flat delivery
Anywhere in Florida, any size order
FREE delivery
On orders over $5,000
Ready in 3 business days
or less, depending on order size
Volume pricing: 3% off $5K+, 5% off $10K+, 8% off $20K+, 10% off $30K+ (aluminum max 5%)
Panel width
16"
Rib height
1"
Min. slope
3/12 (0.5/12 with lap sealant)
Substrates
26ga or 24ga Galvalume steel; .032" aluminum
About this panel
The standing seam look for less
Low rib, clean lines
The low 1" rib on a 16" panel gives a clean, modern look on homes, porches, sheds and outbuildings. On roofs of 3/12 and steeper no sealant is needed; on lower slopes down to 0.5/12, a sealant bead is added at the seam.
Fast to install
No clips to lay out or buy. Crews screw through the hidden flange and keep moving, which is why TrueShield 100 is a favorite for porches, additions, sheds and budget-minded re-roofs.
Panel features
Specs at a glance
- Panel width16"
- Rib height1"
- Min. slope3/12 (0.5/12 with lap sealant)
- AttachmentConcealed screw flange (low-profile pancake screws)
- Substrates26ga or 24ga Galvalume steel; .032" aluminum
- FinishesGalvalume, SMP, Kynar 500
- LengthCut to length, up to 40 ft online (up to 55 ft by phone)
Panel profile
TrueShield 100
Pricing
Price per linear foot
Cut to your length. Same price online, by phone and at the counter.
26 Gauge
Galvalume (mill finish)
Order →
$2.61/ft
26 Gauge
SMP painted
Order →
$3.66/ft
26 Gauge
Kynar 500 painted
Order →
$4.99/ft
24 Gauge
Galvalume (mill finish)
Order →
$3.35/ft
24 Gauge
Kynar 500 painted
Order →
$5.97/ft
.032 Aluminum
Kynar 500 painted
Order →
$8.49/ft
3 ft minimum panel length. Trims, clips and fasteners for this panel are sold on the order page.
Colors
Available colors
Kynar 500 Colors
PVDF finish · 26ga, 24ga and .032 aluminum · "Special order" = special order in 26ga
SMP Colors
Siliconized modified polyester · 26 gauge
Bare Metal
Galvalume mill finish · 26ga and 24ga
Colors on screen are approximate. Ask for a color chip or see the metal at our Tampa counter before you order.
Technical
Specifications & approvals
Substructure
- Plywood
- 15/32" CDX minimum
- Underlayment
- High-temp self-adhered recommended
- Fasteners
- Low-profile pancake screws (stainless on the coast)
Substrates
- Painted
- AZ50 Galvalume steel (ASTM A792)
- Mill finish
- AZ55 Galvalume steel
- Aluminum
- .032" aluminum, Kynar 500
Approvals & Ordering
- Florida Product Approval
- FL# 30343.2 (steel) / FL# 30343.3 (.032 aluminum)
- Deck
- 15/32" CDX plywood
- Cut length
- 3 ft to 40 ft online, to 55 ft by phone
Tampa warehouse
7001 Causeway Blvd, Tampa, FL 33619 · (813) 410-7427
Pickup in Tampa
Open 7 days, 7am–5pm. Most orders are ready in 3 business days or less, depending on size.
Florida delivery
$290 anywhere in Florida, free on orders over $5,000. Tuff Rib-only orders ship for $230. Most orders are ready in 3 business days or less. Outside Florida? We arrange freight nationwide on larger orders.
FAQ
TrueShield 100 questions
Ready to order TrueShield 100?
Pick your gauge, color and lengths. Pickup in Tampa or delivery across Florida.
