ForgeSeam 150
15" Clip-Lock Standing Seam · 1.5" Rib
ForgeSeam 150 is our 15" clip-attached snap-lock panel with a 1.5" rib. Hidden clips hold each panel to the deck and the next panel snaps over the seam, so there are no exposed fasteners and the panels can move freely with the heat.
$290 flat delivery
Anywhere in Florida, any size order
FREE delivery
On orders over $5,000
Ready in 3 business days
or less, depending on order size
Volume pricing: 3% off $5K+, 5% off $10K+, 8% off $20K+, 10% off $30K+ (aluminum max 5%)
Panel width
15"
Rib height
1.5"
Min. slope
2/12 (lower with hot-melt sealant)
Substrates
26ga or 24ga Galvalume steel; .032" aluminum
About this panel
Tighter seams, floating clips
A classic seam pattern
The narrower 15" width puts the seams closer together than IronSeam 150 for a more traditional standing seam look. Rated for slopes as low as 2/12.
Built for long runs
Floating clips let every panel expand and contract through Florida summers without stressing the seams, so long hip-and-valley roofs stay flat and quiet.
Panel features
Specs at a glance
- Panel width15"
- Rib height1.5"
- Min. slope2/12 (lower with hot-melt sealant)
- AttachmentConcealed clips, snap-lock seam
- Substrates26ga or 24ga Galvalume steel; .032" aluminum
- FinishesGalvalume, SMP, Kynar 500
- LengthCut to length, up to 40 ft online (up to 55 ft by phone)
Panel profile
ForgeSeam 150
Pricing
Price per linear foot
Cut to your length. Same price online, by phone and at the counter.
26 Gauge
Galvalume (mill finish)
Order →
$2.61/ft
26 Gauge
SMP painted
Order →
$3.66/ft
26 Gauge
Kynar 500 painted
Order →
$4.99/ft
24 Gauge
Galvalume (mill finish)
Order →
$3.35/ft
24 Gauge
Kynar 500 painted
Order →
$5.97/ft
.032 Aluminum
Kynar 500 painted
Order →
$8.49/ft
3 ft minimum panel length. Trims, clips and fasteners for this panel are sold on the order page.
Colors
Available colors
Kynar 500 Colors
PVDF finish · 26ga, 24ga and .032 aluminum · "Special order" = special order in 26ga
SMP Colors
Siliconized modified polyester · 26 gauge
Bare Metal
Galvalume mill finish · 26ga and 24ga
Colors on screen are approximate. Ask for a color chip or see the metal at our Tampa counter before you order.
Technical
Specifications & approvals
Substructure
- Plywood
- 15/32" CDX minimum
- Underlayment
- High-temp self-adhered recommended
- Fasteners
- Low-profile pancake screws (stainless on the coast)
Substrates
- Painted
- AZ50 Galvalume steel (ASTM A792)
- Mill finish
- AZ55 Galvalume steel
- Aluminum
- .032" aluminum, Kynar 500
Approvals & Ordering
- Florida Product Approval
- FL# 30343.10 (steel) / FL# 30343.5 (.032 aluminum)
- Deck
- 15/32" CDX plywood
- Cut length
- 3 ft to 40 ft online, to 55 ft by phone
Tampa warehouse
7001 Causeway Blvd, Tampa, FL 33619 · (813) 410-7427
Pickup in Tampa
Open 7 days, 7am–5pm. Most orders are ready in 3 business days or less, depending on size.
Florida delivery
$290 anywhere in Florida, free on orders over $5,000. Tuff Rib-only orders ship for $230. Most orders are ready in 3 business days or less. Outside Florida? We arrange freight nationwide on larger orders.
FAQ
ForgeSeam 150 questions
Ready to order ForgeSeam 150?
Pick your gauge, color and lengths. Pickup in Tampa or delivery across Florida.
